| KST Daviga DS213 Servo Specifications | ||
|---|---|---|
| Body dimensions | 23.0 mm wide x 12.0 mm thick x 23.5 mm high | 0.91" wide x 0.47" thick x 0.93" high |
| Max dimensions | 32.0 mm wide x 12.0 mm thick x 28.5 mm high | 1.26" wide x 0.47" thick x 1.12" high |
| Stall torque (4.8V) | 2.5 Kg.cm | 35 oz.in |
| Stall torque (5V) | 2.6 Kg.cm | 36 oz.in |
| Stall torque (6V) | 3 Kg.cm | 42 oz.in |
| Weight | 16.5 g | 0.58 oz |
| Lead length | 21 cm | 8.3 in |
| Operating speed (4.8V) | 0.08 sec/60° | |
| Operating speed (5V) | 0.07 sec/60° | |
| Operating speed (6V) | 0.06 sec/60° | |
| Operating voltage | 4.8V to 6V | |
| Operating temperature | -10 - +50 °C | |
| Bearings | 2 ball races | |
| Gear material | Hardened steel | |
| Case material | 7075 aluminium | |
| Motor type | Coreless DC | |
| Working frequency | 333 Hz | |
| Dead band/resolution | 2 µs | |
| Pulse width for ± 60º | 900-2100 µs | |
| Digital | Yes | |
| Programmable | No | |
| Position feedback | Potentiometer | |
| Supplied accessories | 3 plastic output arms, 2 arm retaining screws, 2 mounting screws | |
| Optional accessories | KST 25T-5 Metal Servo Output Arm, KST 25T-5 Heavy Duty Servo Output Arms, Gear Set for KST X10 | |
Review by: Anonymous
Good servo. No slop, quiet and well made.
Review by: Oleg
KST Daviga DS213 ServoI bought them for my RC Factory Crack Yak XL. These servos are light, fast and accurate. Certainly, they are more expensive than they usually use on foamy planes, but I'm tired of cheap servos that keep breaking regularly for no reason. Have used KST servos in the past with great results. All my electric 3D planes, including 1.5 meters planes from Extreme Flight are on KST servos righ now (all from HyperFlight, by the way). They suite my needs perfectly. As a result I am a fan of KST servos and HyperFlight! And as usual, grate service from Hyperflight!
Review by: Richard
KST Daviga DS213 ServoExcellent servo that is precise and work silently and well made.
